Name: IEC60076 Zero Sequence Current Sense Transformer Active Type
Brand: Shinhom
Price: 1 USD

Brand Name : Shinhom

Model Number : HKC Series

Certification : CE IEC RoHS

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Payment Terms : T/T

Supply Ability : 10000/MONTH

Delivery Time : 4~8 Weeks

Packaging Details : Carton

Name : Hall Effect Current Sensor/Sense Transformer Transducer

Magnetic Circuit Structure : Single Stage Type

Voltage Transformation Principle : Electromagnetic Type

Installation : Active Type

Standard : IEC60076

Contact Now

Zero Sequence Current Sensor/Sense Transformer Transducer With Operation Current Of 0 To 2000A

Zero Sequence Current Transformer

It can be used for current monitoring and protection in small current grounding systems, fire leakage systems, three-phase current unbalance detection and other equipment.
Main Feature
Enclosed by epoxy resin, good seismic performance
Perforation method, the hole diameter is from φ12mm-φ260mm, which is convenient for busbar installation
High magnetic permeability material with wide measuring range

Electrical Parameter

Type	Input Rated Current(A)	Output Rated Current (mA)		NonLinearity		Second Load(Ω)	Power Frequency Withstand voltage (V)
			Max Rated Times	Precision(±%)	Phase Error
				Precision(±%)	(±')
HKC2150-2B	0~5	0~10	2	0.2	30	≤200	≥3000
HKC21113B	0~5	0~10	2	0.2	30	≤200	≥3000
HKC21125B	0~5	0~10	2	0.2	30	≤200	≥3000
HKC2174B	0~5	0~10	5	0.2	30	≤500	≥3000
HKC21126B	0~5	0~10	5	0.2	30	≤500	≥3000
HKC21127B	0~5	0~10	5	0.2	30	≤500	≥3000
HKC21117B	0~5	0~10	5	0.2	30	≤1000	≥3000
HKC2197B	0~5	0~10	5	0.2	30	≤1000	≥3000
HKC21144B	0~5	0~10	5	0.2	30	≤1000	≥3000
HKC21163B	0~5	0~10	2	0.2	30	≤300	≥3000
HKC21148B	0~5	0~10	2	0.2	30	≤300	≥3000
HKC21162B	0~5	0~10	2	0.2	30	≤300	≥3000
HKC21166B	0~5	0~10	2	0.2	30	≤300	≥3000
HKC21171B	0~5	0~10	2	0.2	30	≤300	≥3000
HKC21169B	200	500	2	0.5	60	≤10	≥3000
HKC21168B	400	500	2	0.5	60	≤10	≥3000
HKC21105B	800	500	2	0.5	60	≤10	≥3000
HKC21106B	1000	500	2	0.5	30	≤10	≥3000
HKC21107B	2000	500	2	0.5	30	≤10	≥3000
HKC21135B	0~5	0~10	2	0.5	90	≤1000	≥3000
HKC21260B	0~5	0~10	2	0.5	90	≤1000	≥3000

Notes: Product specifications can be customized
